K3V112DTP 9N00 Excavator Hydraulic Main Pumps Assy For EC210 / 240

Place of Origin Korea
Brand Name Own brand
Model Number K3V112DTP
Minimum Order Quantity 1 SETS
Packaging Details wooden box
Delivery Time 1-7 Days for stock items, 10-25 days for production order
Payment Terms T/T , Western Union , RMB
Supply Ability 500 pcs each month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Stock Plenty Model K3V112DTP
Machine EC210 / 240 Appliion Excavator
Quotation Upon Quality Package Carton Or Wooden Box
High Light

K3V112DTP Excavator Hydraulic Main Pumps

,

EC210 Excavator Hydraulic Main Pumps

Leave a Message
Product Description
K3V112DTP 9N00 Excavator Hydraulic Main pumps Assy for EC210/ 240

Product Description






Model NO. K3V112DTP-9N24-14T
Description Hydraulic pump for EC210 EC240 Excavator
Brand name Handok
Color As the photo
Appliion excavator
Condition 100% brand new
Warranty 1 Year
Packing standard packing(fiberboad carton/wooden case)or as customzied
Payment term T/T,Alipay..etc.
Shipment 7days after getting the payment,but not for the customzied item
Remark Any more detailed information about the product,pls donot hestate to inquiry with us.Also welcime to visitour company or factory if you have free time.We will be appriciate for that. Thank you.







List of spare parts

# Part No Part Name Qty.
  SA 1142-00012 Pump 1
1 SA 8230-14650 Piston 2
2 VOE 14500003 Piston 9
3 VOE 14500002 Seat 9
4 SA 8230-28580 Cylinder 1
5 SA 8230-28560 Block 1
6 VOE 14500001 Plate 1
7 SA 8230-28590 Cylinder 1
8 SA 8230-28560 Block 1
9 VOE 14500000 Plate 1
10 SA 8230-09800 Plate 2
11 SA 8230-30540 Plate 1
12 VOE 14500012 Bushing 1
13 SA 7223-00450 Check valve 2
14 SA 7223-00500 Seat 1
15 SA 7223-00520 Guard 1
16 SA 9676-73200 Ball 1
17 SA 7223-00460 Check valve 2
18 SA 7223-00500 Seat 1
19 SA 7223-00540 Guard 1
20 SA 9676-73200 Ball 1
21 SA 8230-09020 Valve 1
22 SA 8230-09100 Shaft 1
23 SA 8230-09070 Shaft 1
24 SA 8230-09660 Coupling 1
25 SA 8230-26610 Roller Bearing 2
26 SA 8230-26700 Needle Bearing 2
27 SA 8230-14530 Spacer 4
28 SA 8230-09370 Plate 2
29 SA 8230-09680 Bushing more 2
30 SA 8230-09710 Spring 18
31 SA 8230-09670 Spacer 2
32 SA 8230-21920 Plate 2
33 SA 8230-08940 Support 2
34 SA 8230-09350 Cover 1
35 SA 8230-08930 Body 1
36 SA 8230-08980 Valve assembly 1
37 SA 8230-09690 Bolt 8
38 SA 9016-10804 Bolt 4
39 SA 9415-11021 Plug 3
40 SA 9415-11051 Plug 4
41 SA 7242-11040 Plug 21
42 SA 8230-09790 Pin 2
43 SA 8230-09320 Pin 1
44 SA 7223-00570 Pin 1
45 SA 8230-09250 Piston 2
46 SA 8230-09640 Stop 2
47 SA 8230-09650 Stop 2
48 SA 9511-22035 O-ring 2
49 SA 9511-22095 O-ring 1
50 SA 9511-22145 O-ring 4
51 SA 9511-12008 O-ring 16
52 SA 9511-12011 O-ring 8
53 SA 9511-12024 O-ring 4
54 SA 9511-12018 O-ring 2
55 SA 8230-26900 Seal 1
56 SA 9566-10180 Ring 2
57 SA 9566-20350 Ring 2
58 SA 8230-25620 Nut 2
59 SA 9111-12000 Nut 2
60 SA 8230-25980 Ring 2
61 SA 8230-26430 Plate 2
62 SA 7223-00660 Spring Pin 4
63 SA 8230-25450 Eye Bolt 2
64 SA 8230-26780 Bolt 2
65 SA 8230-09700 Bolt 2
100 SA 8148-13080 Sealing Kit 1








K3V112DTP 9N00 Excavator Hydraulic Main Pumps Assy For EC210 / 240 0
